Junction Box
IP67 Water Rated Junction Box
This JBW junction box is perfect for damp and wet locations.
- 24Amp 450VAC
- J-Box Accepts 1–6 Wire Configurations
- IP67 Water Rating
- 0.5–2.5mm² Wire Diameter
- TUV / CE / RoHS Approval
Downloads
Technical Specifications
| Finish | Black |
| Model | JBW-2WL | JBW-3WL | JBW-4WL | JBW-5WL | JBW-6WL |
|---|---|---|---|---|---|
| Length | 5.44″ (138.2mm) | 5.44″ (138.2mm) | 5.44″ (138.2mm) | 5.44″ (138.2mm) | 5.44″ (138.2mm) |
| Width | 1.69″ (42.8mm) | 3.2″ (81.2mm) | 4.34″ (110.2mm) | 4.34″ (110.2mm) | 4.34″ (110.2mm) |
| Height | 1.42″ (35.7mm) | 1.42″ (35.7mm) | 1.42″ (35.7mm) | 1.42″ (35.7mm) | 1.42″ (35.7mm) |
Specify Your Product
Ready to build a product that achieves your project goals? Use our tool below to create a custom code and ensure seamless compatibility. Save your design and specifications in a project, and when you're ready to order, find a nearby Kelvix distributor to bring your vision to life.
Product Code:
Make a selection in each category to complete your product code.
1. Item
- JBW — Junction Box
2. Wire Lead
- 2WL — 2 Wire Lead
- 3WL — 3 Wire Lead
- 4WL — 4 Wire Lead
- 5WL — 5 Wire Lead
- 6WL — 6 Wire Lead
