Performance 300 (Outdoor)
PH Series | Rubber-Coated Linear LED Strip Tape
Our most popular linear series! Performance 300 is a terrific combination of lumens, light quality, wattage, and price. The outdoor version is commonly used for exterior wall-washing, brick and step lighting, as well as illuminating architectural details.
- Supports Title 24 JA8-2019 Compliance
- 90+ CRI
- Dimmable
- 50,000 Hour Life
- UL-listed for Indoor and Outdoor Use
- 3M™ Industrial Adhesive Backing
- For Use With 24V Power Supplies
Downloads
Technical Specifications
| Color/Temperature | 2700K, 3000K, 3500K, 4000K, 5000K |
| Dimming Protocol | PWM, TRIAC, 0-10V, DMX 512 |
| Indoor/Outdoor | Outdoor |
| Input Voltage | 24V DC |
| Watts per Foot | 3.2W |
| Optic | 120° |
| Max Run Length | 30ft |
| CRI | 90+ |
| Operating Temp. | -40°F (-40°C) to 149°F (65°C) |
| Cut Intervals | 1.31" (33.3mm) |
| Tape Width | 0.44" (11.2mm) |
| Tape Height | 0.24" (6mm) |
| Diode | 2835 |
| Life Expectancy | 50,000 Hour Life |
| Field Cuttable | No |
| Outer Jacket Material | Silicone |
| PH27K-WR-24V | PH30K-WR-24V | PH35K-WR-24V | PH40K-WR-24V | PH50K-WR-24V | |
|---|---|---|---|---|---|
| Kelvin | 2700K | 3000K | 3500K | 4000K | 5000K |
| Lumens per Foot | 322 lm/ft | 330 lm/ft | 340 lm/ft | 347 lm/ft | 356 lm/ft |
| Lumens per Watt | 100 lm/W | 103 lm/W | 106 lm/W | 108 lm/W | 111 lm/W |
| 1ft | 2ft | 3ft | 4ft | 5ft | 6ft | 7ft | 8ft | 9ft | 10ft | 11ft | 12ft | 13ft | 14ft | 15ft |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4.2 | 8.5 | 12.7 | 16.8 | 21 | 25.4 | 29.2 | 32.9 | 36.9 | 40.5 | 44.2 | 48 | 51.4 | 54.6 | 57.7 |
| 16ft | 17ft | 18ft | 19ft | 20ft | 21ft | 22ft | 23ft | 24ft | 25ft | 26ft | 27ft | 28ft | 29ft | 30ft |
| 60.7 | 64.3 | 67 | 70.4 | 71.8 | 75.2 | 77.7 | 80 | 83 | 85.1 | 86.6 | 88.7 | 91.2 | 93.7 | 94.6 |
Specify Your Product
Ready to build a product that achieves your project goals? Use our tool below to create a custom code and ensure seamless compatibility. Save your design and specifications in a project, and when you're ready to order, find a nearby Kelvix distributor to bring your vision to life.
Product Code:
Make a selection in each category to complete your product code.
1. Item
- PH27K — Performance 300 2700K
- PH30K — Performance 300 3000K
- PH35K — Performance 300 3500K
- PH40K — Performance 300 4000K
- PH50K — Performance 300 5000K
2. Location
- WR — Outdoor
3. Input Voltage
- 24V — 24V DC
