Performance 100 (Indoor)

PJ Series | Linear LED Strip Tape

Download Spec Sheet Contact Us Add to Project

The indoor Performance 100 Series provides a subtle glow in locations where the lighting should be visually quiet and unpronounced. This is a great night light for toe-kicks and stairs, and also looks amazing underneath beds, sofas, and other furniture.

Supports Title 24 JA8-2019 Compliance
90+ CRI
Dimmable
50,000 Hour Life
UL-listed for Indoor Use
3M™ Industrial Adhesive Backing
For Use With 24V Power Supplies

Downloads

Spec Sheet

Installation Instructions

Installation Instructions

Warranty

Warranty Info

IES Files

Photometric Files

Additional Files

Technical Specifications

Color/Temperature	2400K, 2700K, 3000K, 3500K, 4000K, 5000K
Dimming Protocol	PWM, TRIAC, 0-10V, DMX 512
Indoor/Outdoor	Indoor
Input Voltage	24V DC
Watts per Foot	0.9W
Optic	120°
Max Run Length	40ft
CRI	90+
Operating Temp.	-40°F (-40°C) to 149°F (65°C)
Cut Intervals	2.63" (66.7mm)
Tape Width	0.38" (10mm)
Tape Height	0.06" (1.5mm)
Diode	2835
Life Expectancy	50,000 Hour Life
Field Cuttable	Yes

	PJ24K-24V	PJ27K-24V	PJ3K-24V	PJ35K-24V	PJ40K-24V	PJ5K-24V
Kelvin	2400K	2700K	3000K	3500K	4000K	5000K
Lumens per Foot	53 lm/ft	74 lm/ft	85 lm/ft	88 lm/ft	92 lm/ft	98 lm/ft
Lumens per Watt	58 lm/W	82 lm/W	94 lm/W	97 lm/W	102 lm/W	108 lm/W

Total Wattage Used at Each Length

1ft	2ft	3ft	4ft	5ft	6ft	7ft	8ft	9ft	10ft	11ft	12ft	13ft	14ft	15ft	16ft	17ft	18ft	19ft	20ft
1.1	2.0	3.1	4.0	5.2	6.1	7.2	8.3	9.1	10.3	11.1	12.3	13.3	14.2	15.2	16.0	17.1	17.8	18.9	19.9
21ft	22ft	23ft	24ft	25ft	26ft	27ft	28ft	29ft	30ft	31ft	32ft	33ft	34ft	35ft	36ft	37ft	38ft	39ft	40ft
20.8	21.7	22.5	23.4	24.3	25.4	26.1	27.0	27.8	28.6	29.6	30.4	31.2	32.0	32.6	33.4	34.2	35.1	35.5	36.6

Specify Your Product

Ready to build a product that achieves your project goals? Use our tool below to create a custom code and ensure seamless compatibility. Save your design and specifications in a project, and when you're ready to order, find a nearby Kelvix distributor to bring your vision to life.

Product Code:

Make a selection in each category to complete your product code.

1. Item
