Performance 200 (Indoor)
PL Series | Linear LED Strip Tape
The indoor Performance 200 Series is well suited for mid-level illumination needs, such as toe-kicks and handrails.
- Supports Title 24 JA8-2019 Compliance
- 90+ CRI
- Dimmable
- 50,000 Hour Life
- UL-listed for Indoor Use
- 3M™ Industrial Adhesive Backing
- For Use With 24V Power Supplies
Downloads
Spec Sheet
Spec SheetInstallation Instructions
Warranty
IES Files
Photometric Files
Additional Files
Technical Specifications
| Color/Temperature | 2400K, 2700K, 3000K, 3500K, 4000K, 5000K |
| Dimming Protocol | PWM, TRIAC, 0-10V, DMX 512 |
| Indoor/Outdoor | Indoor |
| Input Voltage | 24V DC |
| Watts per Foot | 1.9W |
| Optic | 120° |
| Max Run Length | 30ft |
| CRI | 90+ |
| Operating Temp. | -40°F (-40°C) to 149°F (65°C) |
| Cut Intervals | 2.63" (66.7mm) |
| Tape Width | 0.38" (10mm) |
| Tape Height | 0.06" (1.5mm) |
| Diode | 2835 |
| Life Expectancy | 50,000 Hour Life |
| Field Cuttable | Yes |
| PL24K-24V | PL27K-24V | PL3K-24V | PL35K-24V | PL40K-24V | PL5K-24V | |
|---|---|---|---|---|---|---|
| Kelvin | 2400K | 2700K | 3000K | 3500K | 4000K | 5000K |
| Lumens per Foot | 106 lm/ft | 148 lm/ft | 169 lm/ft | 176 lm/ft | 184 lm/ft | 195 lm/ft |
| Lumens per Watt | 55 lm/W | 77 lm/W | 88 lm/W | 92 lm/W | 96 lm/W | 102 lm/W |
| 1ft | 2ft | 3ft | 4ft | 5ft | 6ft | 7ft | 8ft | 9ft | 10ft | 11ft | 12ft | 13ft | 14ft | 15ft |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.1 | 5.2 | 8.2 | 9.6 | 12.4 | 14.4 | 17.2 | 18.7 | 21.6 | 23 | 25.8 | 26.9 | 29.7 | 31.5 | 33.8 |
| 16ft | 17ft | 18ft | 19ft | 20ft | 21ft | 22ft | 23ft | 24ft | 25ft | 26ft | 27ft | 28ft | 29ft | 30ft |
| 35.1 | 37.1 | 38 | 40.7 | 41.9 | 43.9 | 46.6 | 47.7 | 49.9 | 50.7 | 52.4 | 54.2 | 55.6 | 57.5 | 57.8 |
Specify Your Product
Ready to build a product that achieves your project goals? Use our tool below to create a custom code and ensure seamless compatibility. Save your design and specifications in a project, and when you're ready to order, find a nearby Kelvix distributor to bring your vision to life.
Product Code:
Make a selection in each category to complete your product code.
1. Item
- PL24K — Performance 200 2400K
- PL27K — Performance 200 2700K
- PL3K — Performance 200 3000K
- PL35K — Performance 200 3500K
- PL40K — Performance 200 4000K
- PL5K — Performance 200 5000K
2. Input Voltage
- 24V — 24V DC
Standards and Certifications
