Performance 100 (Outdoor)

PJ Series | Rubber-Coated Linear LED Strip Tape

The outdoor Performance 100 Series provides even illumination at low light-levels. This series is ideal for accenting architectural elements. In addition, this series is commonly used as safety illumination for outdoor paths and walkways.


  • Supports Title 24 JA8-2019 Compliance
  • 90+ CRI
  • Dimmable
  • 50,000 Hour Life
  • UL-listed for Indoor and Outdoor Use
  • 3M™ Industrial Adhesive Backing
  • For Use With 24V Power Supplies
PJ series indoor HERO 1500x1500
PJ series indoor HERO 1500x1500
video
Pl series outdoor dimensions
Pl series nest
Pl series close

Downloads

Technical Specifications

Color/Temperature 2700K, 3000K, 3500K, 4000K, 5000K
Dimming Protocol PWM, TRIAC, 0-10V, DMX 512
Indoor/Outdoor Outdoor
Input Voltage 24V DC
Watts per Foot 0.9W
Optic 120°
Max Run Length 40ft
CRI 90+
Operating Temp. -40°F (-40°C) to 149°F (65°C)
Cut Intervals 2.63" (66.7mm)
Tape Width 0.44" (11.2mm)
Tape Height 0.24" (6mm)
Diode 2835
Life Expectancy 50,000 Hour Life
Field Cuttable No
Outer Jacket Material Silicone
PJ27K-WR-24V PJ3K-WR-24V PJ35K-WR-24V PJ40K-WR-24V PJ5K-WR-24V
Kelvin 2700K 3000K 3500K 4000K 5000K
Lumens per Foot 74 lm/ft 85 lm/ft 88 lm/ft 92 lm/ft 98 lm/ft
Lumens per Watt 82 lm/W 94 lm/W 97 lm/W 102 lm/W 108 lm/W


Total Wattage Used at Each Length
1ft 2ft 3ft 4ft 5ft 6ft 7ft 8ft 9ft 10ft 11ft 12ft 13ft 14ft 15ft 16ft 17ft 18ft 19ft 20ft
1.1 2.0 3.1 4.0 5.2 6.1 7.2 8.3 9.1 10.3 11.1 12.3 13.3 14.2 15.2 16.0 17.1 17.8 18.9 19.9
21ft 22ft 23ft 24ft 25ft 26ft 27ft 28ft 29ft 30ft 31ft 32ft 33ft 34ft 35ft 36ft 37ft 38ft 39ft 40ft
20.8 21.7 22.5 23.4 24.3 25.4 26.1 27.0 27.8 28.6 29.6 30.4 31.2 32.0 32.6 33.4 34.2 35.1 35.5 36.6
