Uniform Thin Line (Outdoor)
UNIx-TL Series | Extra Thin Outdoor LED Strip Tape
Our Uniform series provides single bin color consistency across every single output option. Uniform Thin Line provides a solution for projects with exceptionally small dimensional requirements.
- Uses U2835 Diode
- Create a Custom Fixture with Kelvix Channels
- 5-Year Warranty
- UL-Listed for Indoor and Outdoor
- 3M™ Industrial Adhesive Backing
- For Use with 24V Power Supplies
- Dimmable Using Kelvix Power Supplies
- IP67
- Offering 1-Step, 2-Step, and 3-Step SDCM
Downloads
Technical Specifications
| Series | UNI1-TL / UNI2-TL / UNI3-TL |
| Temp/Color* | 1800K–6500K |
| Input Voltage | 24V DC/Constant Voltage |
| Beam Spread | 120° |
| CRI | 90–97 |
| SDCM | 1-Step, 2-Step, and 3-Step |
| Diode | 2835 |
| Diode Pitch | 0.23" (5.8mm) |
| Cut Intervals | 1.41" (35.7mm) |
| Dimensions | 0.32" (8.1mm) x 0.16" (4.0mm) |
| Dimensions w/End Caps | 0.40" (10.2mm) x 0.22" (5.5mm) |
| Operating Temp. | -4°F (-20°C) to 140°F (60°C) |
| Storage Temp. | -4°F (-20°C) to 158°F (70°C) |
* Customizable—Consult Factory
| 1-Step 100 | 1-Step 200 | 1-Step 300 | 2-Step 100 | 2-Step 200 | 2-Step 300 | 3-Step 100 | 3-Step 200 | 3-Step 300 | |
|---|---|---|---|---|---|---|---|---|---|
| 1800K (lm/ft) | 62 | 130 | 208 | 65 | 136 | 216 | 68 | 132 | 203 |
| 2200K (lm/ft) | 76 | 159 | 255 | 80 | 166 | 264 | 84 | 161 | 248 |
| 2400K (lm/ft) | 77 | 160 | 255 | 80 | 167 | 265 | 84 | 162 | 249 |
| 2700K (lm/ft) | 80 | 166 | 266 | 83 | 174 | 276 | 87 | 168 | 259 |
| 3000K (lm/ft) | 99 | 206 | 329 | 103 | 215 | 342 | 108 | 208 | 321 |
| 3500K (lm/ft) | 103 | 216 | 345 | 108 | 225 | 358 | 113 | 218 | 336 |
| 4000K (lm/ft) | 93 | 194 | 310 | 97 | 203 | 322 | 102 | 196 | 302 |
| 5000K (lm/ft) | 90 | 187 | 299 | 94 | 196 | 311 | 98 | 189 | 292 |
| 6500K (lm/ft) | 93 | 193 | 309 | 97 | 202 | 321 | 101 | 195 | 301 |
| Wattage1 (per ft) | 1.1 | 2.1 | 3.4 | 1.1 | 2.1 | 3.4 | 0.9 | 1.9 | 2.8 |
| Efficiency (lm/W) | 90 | 98 | 97 | 94 | 103 | 101 | 120 | 110 | 115 |
| Max Run Length (ft) | 37 | 22 | 17 | 37 | 22 | 17 | 37 | 24 | 21 |
Specify Your Product
Ready to build a product that achieves your project goals? Use our tool below to create a custom code and ensure seamless compatibility. Save your design and specifications in a project, and when you're ready to order, find a nearby Kelvix distributor to bring your vision to life.
Product Code:
Make a selection in each category to complete your product code.
1. Series
- UNI1-TL — Uniform Thin Line 1-Step
- UNI2-TL — Uniform Thin Line 2-Step
- UNI3-TL — Uniform Thin Line 3-Step
2. Location
- O — Outdoor
3. Output*
- 100 — 100 lm/ft
- 200 — 200 lm/ft
- 300 — 300 lm/ft
4. Temp/Colors*
- 18K — 1800K
- 22K — 2200K
- 24K — 2400K
- 27K — 2700K
- 30K — 3000K
- 35K — 3500K
- 40K — 4000K
- 50K — 5000K
- 65K — 6500K
5. Voltage
- 24V — 24V DC
6. Modifications
- NA — None
* Customizable—Consult Factory
Standards and Certifications
Power/Connect Options
Lead
FML-2C-1
12.00" (305.0mm)
FML-2C-2
24.00" (0.60m)
FML-2C-3
36.00" (0.91m)
FML-2C-6
72.00" (1.82m)
FML-2C-12
144.00" (3.65m)
FML-2C-15
180.00" (4.57m)
FML-2C-20
240.00" (6.09m)
Lead with DC Plug
FML-2C-DC-1-M
12" (305mm)
FML-2C-DC-1-F
12" (305mm)
FML-2C-DC-6-M
72" (1.82m)
FML-2C-DC-6-F
72" (1.82m)
FML-2C-DC-10-M
120" (3.04m)
FML-2C-DC-10-F
120" (3.04m)
Connectors
FMC-2C-1.5|
1.5" (38mm)
FMC-2C-3I
3" (76mm)
FMC-2C-6I
6" (152mm)
FMC-2C-9I
9" (228mm)
FMC-2C-1
12" (305mm)
FMC-2C-2
24" (0.60m)
