8Bit/16Bit DMX Decoder

DMXD-4C-RDM16-5A-TB

Download Spec Sheet Contact Us Add to Project

Unlock precise lighting control with our 4-channel 8-bit/16-bit DMX Decoder. Delivering 5 amps per channel and offering three dimming curve options, this compact decoder seamlessly integrates into DMX systems for versatile and dynamic lighting experiences in any setting.

O-LED Display for Setting Adjustment and Monitoring
Switchable Logarithmic or Linear Dimming
Capable of Both 8-Bit & 16-Bit Control
5 Year Warranty
Standard and Bi-directional DMX512 Communication
Supports Remote Management via RDM Protocol
Short Circuit / Over Current / Over-Heat Protection
Adjustable Pulse-Width Modulation (PWM)
Pre-built Test Scenes for “Self-Testing”

Downloads

Spec Sheet

Warranty

Warranty Info

Technical Specifications

Model	DMXD-4C-RDM16-5A-TB
Input Voltage	5–24V DC
Output	4 X 5A
Constant Voltage	Yes
Length	7″ (177.8mm)
Width	1.73″ (44.05mm)
Height	1.19″ (30.16mm)
Pixel Protocols	50+
IP Rating	IP20
Operating Temperature	-22F (-30 °C) to 130F (54.44 °C)
Storage Temperature	-40F (-40 °C) to 176F (80 °C)
