AC Fizzix

FZXAC Series | 120V Modular Linear LED Lighting System

Download Spec Sheet Contact Us Add to Project

As an expansion to the Fizzix™ product family, AC Fizzix offers integrated 120V diode-free illumination combined with various length options available. AC Fizzix is affordable and simple to install, offering straight and corner connectors. AC Fizzix is a great fit for linear installations such as displays, coves, undercabinet, and direct-view lighting.

Direct View Without Diode Imaging
Easy Linking
Straight & Corner Connection
Up to 65.6ft Maximum Run Length
Supports Title 24 JA8-2019 Compliance
TRIAC/ELV Dimmable

Downloads

Spec Sheet

Installation Instructions

Installation Instructions

Warranty

Warranty Info

IES Files

Additional Files

Technical Specifications

Length	6.0" (152mm), 8.0" (203mm), 12.0" (305mm), 24.0" (609mm), 36.0" (915mm), 48.0" (1219mm)
Color/Temperature	2700K, 3000K, 3500K, 4000K, 5000K
Dimming Protocol	Triac, ELV
Finish	Silver
Input Voltage	120V AC
Lumens per watt	60 lm/W
Beam Angle	120°
Max Run Length	65.6ft
Operating Temp.	-4°F (-20°C) to 113°F (45°C)
Storage Temp.	-4°F (-20°C) to 140°F (60°C)
