Floptix™ Asymmetric

FXA Series | Flexible Optics

Floptix combines flexible led and architectural optics into a versatile system with a multitude of indoor and outdoor applications.

  • Factory Built to Length
  • 110º × 70º Asymmetric Beam
  • Flexible
  • IP67
Floptixasymmetric 45deg hero 1500x1500px
Floptixasymmetric 45deg hero 1500x1500px
Floptix Asymmetric 45 w Channel 1500x1500px
Floptix Asymmetric S High 1500x1500px
Floptix Asymm Textured Wall Lit 1500x1500px

Downloads

Spec Sheet

Spec Sheet

Installation Instructions

Additional Files

Technical Specifications

Color/Temperature 2400K, 2700K, 3000K, 3500K, 4000K, 5000K
Dimming Protocol PWM, TRIAC, 0-10V, DMX 512
Indoor/Outdoor Indoor/Outdoor
Input Voltage 24V DC
Watts per Foot 5.85W
Beam Angle 110° × 70°
Max Run Length 16ft
CRI 90+
Operating Temperature -40°F (-40°C) to 113°F (45°C)
Cut Intervals 6.57" (167mm)
Tape Width 0.91" (23mm)
Tape Height 0.41" (10.5mm)
Field Cuttable No
Feed Orientation Side Feed Left, Side Feed Right, End Feed, Bottom Feed
Bend Radius 7.09" (180mm)
FXA-24K-450 FXA-27K-450 FXA-30K-450 FXA-35K-450 FXA-40K-450 FXA-50K-450
Kelvin 2400K 2700K 3000K 3500K 4000K 5000K
Lumens per foot 352 lm/ft 353 lm/ft 438 lm/ft 443 lm/ft 454 lm/ft 478 lm/ft
Lumens per watt 60 lm/W 60 lm/W 74 lm/W 75 lm/W 77 lm/W 81 lm/W

Standards and Certifications

Related Projects

Mounting Options

Mounting Clips

Floptix mountingclips 450x450
Fx cm clp
Length
0.59″ (15mm)
Width
1.05″ (26.7mm)
Internal Width
0.99" (25.3mm)
Height
0.45" (11.5mm)
Material
Stainless Steel

Channel

Floptix 45 wchannel 450x450
Fx cm ch
Length
39.37" (1m)
Width
1.18" (30mm)
Internal Width
1.08" (27.5mm)
Height
0.42" (10.7mm)
Material
Aluminum
