HLV36-SC
36 Watt–24 Volt | Class 2 Power Supply
Illuminate indoor spaces with confidence using the HLV36-SC, a versatile 36W constant voltage LED power supply designed to adapt seamlessly to various dimming systems. Ensuring reliable operation with built-in protective measures, this power supply embraces a robust design for efficient performance. UL-listed as Class 2 and suitable for Dry, Damp and Wet locations, it offers a reliable and adaptable solution for your indoor/outdoor lighting needs.
Product Features
- Flicker-free Dimming Down to ≤1%
- TRIAC, ELV, MLV, or 1–10V Dimming
- Protections: Short Circuit/Over Current/Over Voltage
- Free Air Convection Cooling
- Suitable for Dry/Damp/Wet Location
- UL-listed Class 2
Downloads
Spec Sheet
Spec SheetTechnical Specifications
| Series | HLV36-SC |
| Input Voltage | 100–277V AC |
| Output Voltage | 24V DC / Constant Voltage |
| Max Wattage | 36W |
| Temp Range | -20°F(-29°C) – 158°F (70°C) |
| Dimensions | 10.27" × 1.26" × 0.78" |
| Classification | Class 2 |
Your Product Code
Use our tool below to create a custom product code and view product compatibility. After making the selections, save the product to a project to keep all your products and specs together in one organized place. Once final, you can order from a nearby distributor.
Product Code:
1. HLV36
- HLV36 — HLV36
2. SC
- SC — SC
Standards and Certifications
