Flexfit™ Color Tuning

Discontinued Color Tuning Flexible LED Sheet
Contact Us Add to Project

Discontinued

Certain graphics respond best to warmer or cooler back-lighting tones, making Color Tuning FlexFit™ ideal for back-lighting installations where graphics are changed regularly. For ease of installation the product can be secured with screws, or adhered using the integral 3M® VHB backing.


  • Ability to Mix Kelvin Temperatures
  • Cuttable Around Every Diode to Create Unique Shape
  • Screw Mount or 3M™ Adhesive Options For Easy Instalation
  • 50,000 Hour Life
  • UL-Listed
Flexfit ct hero 1500x1500
Flexfit ct hero 1500x1500
Flexfit ct curved 150x1500
Flexfit ct closeup 1500x1500
Flexfit ct lit 1500x1500

Downloads

Warranty

Additional Files

Technical Specifications

Color/Temperature 1800K – 6500K
Dimming Protocol 0-10V, DMX 512, DALI
Indoor/Outdoor Indoor/Outdoor
Input Voltage 24V DC
Optic 120°
Max Connection 96W
CRI 90
Operating Temp. -4°F (-20°C) to 113°F (45°C)
FF1 Dimensions 12" × 12" × 0.063" (304.8mm × 304.8mm × 1.6mm)
FF2 Dimensions 12" × 24" × 0.063" (304.8mm × 609.6mm × 1.6mm)
LED Count 288 per sq foot
image Flexfit ct productdims
FF1-CT-20W FF1-CT-30W
Wattage 20W 30W
Lumens 1400 lm/ft² 2100 lm/ft²

Specify Your Product

This product is discontinued. Contact us for help.
