0-10V 2 Channel Dimmer
0-10V-2CH
- 2-Channel 0-10V Dimming Module
- Flicker Free 0-100% Dimming
- Independent Control of Color Temperature and Intensity
- Dual PWM Output
Downloads
Spec Sheet
Spec SheetWarranty
Technical Specifications
| Series | 0-10V |
| Input Voltage | 8-48V DC |
| Output Voltage | 2 x 5A |
| Control Voltage | 0/1-10VDC Dimmer |
| Dimming Range | 0% - 100% |
| Dimming Protocol | 0 - 10V |
| Length | 3.86in (98.0mm) |
| Width | 1.73in (44.0mm) |
| Height | 0.57in (14.5mm) |
| IP Rating | IP20 |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Indoor/Outdoor | Indoor |
Your Product Code
Ready to build a product that achieves your project goals? Use our tool below to create a custom code and ensure seamless compatibility. Save your design and specifications in a project, and when you're ready to order, find a nearby Kelvix distributor to bring your vision to life.
Product Code:
1. 0
- 0 — 0
2. 10V
- 10V — 10V
3. 2CH
- 2CH — 2CH
Standards and Certifications
